XIFLON PVDF RODS are semi-finished products manufactured from high-performance polyvinylidene fluoride (PVDF) resin, sourced from carefully selected and trusted suppliers including XIFLON fluoropolymer resin.
Excellent resistance to acids, bases, and solvents; stable in harsh chemical environments.
Service temperature from −40 °C to +120 °C; melting point 170±10 °C ensures reliability.
Tensile strength ≥ 35 MPa, elongation ≥ 25 %, and hardness ≥ 74 Shore D for durability.
High dielectric strength, low moisture uptake, and smooth, contamination-free surfaces.
Our PVDF rods are extruded or molded from high-purity PVDF resin under strict quality control.
This ensures smooth, contaminant-free surfaces, stable round dimensions, and consistent chemical, thermal, and electrical performance across machining and industrial applications.
Accurate diameters with tight tolerances and reliable machinability.
Smooth, clean rod surfaces free from inclusions or metal particles.
Tensile ≥ 35 MPa, elongation ≥ 25 %, hardness ≥ 74 Shore D ensure durability.
Validated to ASTM standards with traceable data for consistent performance.
| Basic Properties | Test Method | Unit | Value |
|---|---|---|---|
| Specific gravity | ASTM D792 | – | 1.75–1.79 |
| Tensile Strength at Break | ASTM D638 | MPa | ≥ 35 |
| Elongation at Break | ASTM D638 | % | ≥ 25 |
| Hardness | ASTM D2240 | Shore D | ≥ 74 |
| Melting Point | ASTM D3418 | °C | 170±10 |
| Limiting Oxygen Index | ASTM D2863 | % | > 44 |
| Diameter, mm |
Length, mm |
Diameter Tolerance |
|---|---|---|
| 10 | 1000 | 0 / +3 % |
| 12 | ||
| 15 | ||
| 20 | ||
| 25 | ||
| 30 | ||
| 35 | ||
| 40 | ||
| 45 | ||
| 50 | ||
| 60 | ||
| 70 | ||
| 80 |
| Diameter, mm |
Length, mm |
Diameter Tolerance |
|---|---|---|
| 90 | 1000 | 0 / +3 % |
| 100 | ||
| 110 | ||
| 115 | ||
| 120 | ||
| 125 | ||
| 130 | ||
| 140 | ||
| 150 | ||
| 160 | ||
| 170 | ||
| 180 | ||
| 200 |
are available upon request to meet specific application specifications. Length is supplied according to customer requirements.
This controlled extrusion/molding process delivers high-performance PVDF RODS with smooth, defect-free surfaces and accurate diameters. With excellent chemical resistance, strong mechanical integrity, and stable dielectric behavior, XIFLON PVDF rods provide dependable performance in machining and demanding applications.
Applications: Seals, gaskets, and valve parts for pumps and process equipment
Applications: Seals, gaskets, and valve parts for pumps and process equipment
Applications: Insulators, spacers, and dielectric components
Applications: Bushings, bearings, and custom machined parts resistant to corrosive media
Applications: High-purity precision components with smooth finishes
Applications: Hygienic seals, fittings, and machined parts for tanks and processing equipment
Xiflon PVDF RODS are engineered to meet stringent global safety, environmental, and industry-specific standards. Our materials are tested and certified to ensure suitability across critical sectors, including chemical processing, automotive and other industry sectors.
Standard diameters 10–90 mm in 1000 mm lengths; custom cuts available. Length tolerance 0 / +3 %.
Smooth, defect-free surfaces free of inclusions or metal particles, manufactured under strict quality control.
Service range −40 °C to +120 °C; melting point 170 ± 10 °C; reliable chemical and dielectric behavior.
Ideal for seals, gaskets, valve/pump parts, insulators and fittings across chemical, water-treatment and electrical uses.
Diameters: 10, 12, 15, 20, 25, 30, 35, 40, 45, 50, 60, 70, 80, 90 mm • Length: 1000 mm (custom lengths on request).
Store clean, dry, cool; avoid sunlight/heat/oxidizers. Condition at room temp before machining.
Typical values: tensile ≥ 35 MPa, elongation ≥ 25 %, hardness ≥ 74 Shore D (ASTM methods).
Diameter/length tolerance 0 / +3 %; precision cutting available to specification.
Access our PVDF rod dimensions and technical documentation.
Download PVDF Rods TDSPVDF rods are cylindrical semi-finished products made from polyvinylidene fluoride (PVDF), a high-performance thermoplastic fluoropolymer. They are manufactured by either extrusion or compression molding to produce strong, machinable stock.
Manufacturing methods:
Key characteristics of PVDF rods:
Best choice when: PTFE is too soft, and you need durable, strong, and chemical-resistant rods.
PVDF rods are available in a broad range of sizes for machining and industrial applications.
Extruded PVDF rods:
Molded PVDF rods:
Custom options:
Tolerances:
Whether you need long rods for multiple parts or large billets for heavy machining, PVDF rods cover the full range.
PVDF rods combine mechanical toughness, weather resistance, and chemical durability — setting them apart from other fluoropolymers.
PVDF vs. PTFE rods:
PVDF vs. PFA rods:
PVDF vs. ETFE rods:
Summary guide:
PVDF rods are among the easiest fluoropolymers to machine, making them ideal for precision parts.
Machining benefits:
Machining guidelines:
Common machined parts from PVDF rods:
If you need dimensionally stable, easy-to-machine fluoropolymer parts, PVDF rods are an excellent stock material.
PVDF rods are used across industries where strength, chemical resistance, and long-term durability are essential.
Industries & applications:
Bottom line: PVDF rods are ideal when industries demand durability, machinability, and resistance to chemicals and weathering in one material.
